4 Mounting
4.4 Mounting the antennas
1. Connect the SMA connectors of the antennas or antenna cables.
2. Attach the antennas to the designated locations.
ATTENTION!
Tighten the screw connections of the antennas or antenna cables only hand-
tight.
FURTHER NOTES ON ANTENNA INSTALLATION!
You will find further information on antenna mounting and alignment in our
Antenna 101 → https://lp.schildknecht.ag/en/whitepaper-antenna101
Manual
DATAEAGLE 4000 Series - Wireless ETHERNET
22
