6 Commissioning
Configuration parameters 915 MHz
Value Description Comment
HF Rate Modulation method 30k (LR DSSS FEC) @ 500kHz
Bandwidth - Channel 1-51
240k (LR DSSS FEC) @ 500 kHz
Bandwidth - Channel 1-51
400k (GFSK) @ 500 kHz
Bandwidth - Channel 1-51
Channel Radio channel 01: 902.5 MHz
02: 903 MHz
…… 500 kHz / Channel
51: 927,5 MHz
HF Power Level Transmitting power 12-25 dBm
ATTENTION!
Selectable settings are FCC Part 15 compliant. Other combinations are
not permitted!
NOTE: The higher the RF rate, the faster the transmission but the range is
shorter
All devices in a radio system must be set to the same radio channel.
DATAEAGLE radio systems in parallel operation are to be operated with
different radio channels!
It makes sense to reduce the transmitting power in order not to influence
neighboring radio systems in the same frequency band!
Manual
DATAEAGLE 4000 Series - Wireless ETHERNET
37
