Term
Function
Technical data
Description
17
RELAY-1
Output 1A/28VDC
This relay has programmable function,
selectable from a list.
18
RELAY-2
Output 1A/28VDC
This relay has programmable function,
selectable from a list.
19
HORN RELAY OUTPUT
Output 1A/28VDC
This relay controls the horn
20
REMOTE START OUTPUT
Output 1A/28VDC
This relay is used for remote start signal.
21
DIGITAL INPUT - 1:
EMERGENCY STOP
Digital inputs
These inputs have programmable
characteristics selected via the program
menu. Each input may be driven by a
‘normally closed’ or ‘normally open’ contact,
switching either battery+ or battery-. The effect
of the switch is also selectable from a list. See
PROGRAMMING section for more details.
22
DIGITAL INPUT - 2:
SPARE-1
23
PROGRAM LOCK
24
DIGITAL INPUT - 3:
SPARE-2
25
DIGITAL INPUT - 4:
SPARE-3
26
DIGITAL INPUT - 5:
FAULT RESET
27
DIGITAL INPUT - 6:
ALARM MUTE
28
DIGITAL INPUT - 7:
PANEL LOCK
29
CURR_1+
Current transformer
inputs, 5A-AC
Connect the load current transformer
terminals to these inputs. Do not connect the
same current transformer to other instruments
otherwise a unit fault will occur. Connect each
terminal of the transformer to the unit’s related
terminal. Do not use common terminals. Do
not use grounding. Correct polarity of
connection is vital. If the measured power is
negative, then change the polarity of each 3
current transformers. The rating of the
transformers should be the same for each of
the 3 phases. The secondary winding rating
shall be 5 Amperes. (For ex. 200/5 Amps).
30
CURR_1-
31
CURR_2+
32
CURR_2-
33
CURR_3+
34
CURR_3-
