Datakom DKG-329 User Manual

DKG-329 User Manual V-12 (09.10.2012)
- 9 -
Screen
Description
Contents
1
Mains parameters
(phase to neutral)
Genset status
Mains Volts L1, Mains Frequency
Mains Volts L2 , Battery Voltage
Mains Volts L3,
2
Mains parameters
(phase to phase)
Genset status
Mains Volts L1-L2, Mains Frequency
Mains Volts L2-L3, Battery Voltage
Mains Volts L3-L1,
3
Genset parameters
(phase to neutral)
Genset status
Genset Volts L1, Genset Frequency
Genset Volts L2, Battery Voltage
Genset Volts L3,
4
Genset parameters
(phase to phase)
Genset status
Genset Volts L1-L2, Genset Frequency
Genset Volts L2-L3, Battery Voltage
Genset Volts L3-L1,
5
Load parameters
(currents)
Genset status
Load Current L1, Load Frequency
Load Current L2, Load Active Power (kW)
Load Current L3, Load Power Factor
6
Load Phase Power
parameters
Genset status
Genset Phase L1 : Active Power(kW) / Power Factor
Genset Phase L2 : Active Power(kW) / Power Factor
Genset Phase L3 : Active Power(kW) / Power Factor
7
Load Phase Power
parameters
Genset status
Genset Phase L1 : Reactive Power(kVAr)
Genset Phase L2 : Reactive Power(kVAr)
Genset Phase L3 : Reactive Power(kVAr)
8
Synchroscope
Phase Angle
Voltage difference mains_L1 – gen_L1
Frequency difference mains-gen
Angle difference mains-gen
9
Company Logo
10
Alarm List
If no alarm exists, ‘END OF ALARM LIST’ will be displayed.
Existing alarms, load_dumps and warnings will be displayed
as one screen for each entry. Switching to the next entry will
be made with the ▼ button.
11
Date-Time,
Software Version
Date and time.
Operating software version.
12
Statistical Counters 1 / 2
Engine Hours Run
Total Genset Active Power (kW-h)
13
Statistical Counters 2/ 2
Engine Hours to Service
Time to Service
14
Event Records
The unit provides information about last 100 events, starting
from the most recent one.
Please review chapter 10 for detailed information about event
logging.
