Datakom DKG-509 User Manual

DKG-509 User Manual V-29 (23.08.2013)
- 27 -
If the unit is used in a single phase electrical network, it is advised t set the Single Phase
Enable program parameter in CONTROLLER CONFIGURATION group to 1.
When Single Phase Enable is set to 1, then the unit will measure electrical parameters only
on phases L1 of genset and mains.
Voltage and overcurrent checks will be performed on phases L1 only.
Phases L2 and L3 parameters, as well as phase-to-phase voltages are removed from display
screens.
If the unit is fitted with an internal modem, it is not possible to use the serial port for
programming.
Place the SIM card inside the SIM card holder at the back of the unit. Screw the antenna to
the antenna terminal.
Setting of phone and SMS numbers are the same as the external modem.
6.28. Internal GSM Modem
6.27. Single Phase Operation
