DATAKOM DKG-705 User’s Manual
705_USER.doc - 48 -
No: FUNCTION
000 Choke Relay
001 Preheat Relay
002 Start Relay
003 Alarm Relay (timed)
004 Generator Contactor Relay
005 Mains Contactor Relay
006 Fuel Relay
007 Stop Relay
008 Load Shedding Relay
009 Alarm Relay (without timeout)
010 Load Contactor relay for dual
011 Auto ready
012 Master request relay for dual
013 Exerciser on
014 not used
015 not used
016 Shutdown: Digital Input_0
017 Shutdown: Digital Input_1
018 Shutdown: Digital Input_2
019 Shutdown: Digital Input_3
020 Shutdown: Digital Input_4
021 Shutdown: Digital Input_5
022 Shutdown: Digital Input_6
023 Shutdown: Digital Input_7
024 not used
025 Shutdown: Gen Under-Frequency
026 Shutdown: Gen Over Frequency
027 Shutdown: High Battery Voltage
028 Shutdown: Low Fuel Level
029 Shutdown: High Oil Temp. Mea.
030 Shutdown: High Temp. Measured
031 Shutdown: Low Oil Pressure Mea.
032 Shutdown: Fail To Stop
033 Shutdown: Fail To Start
034 Shutdown: Genset Low Voltage
035 Shutdown: Genset High Voltage
036 Shutdown: Slave not available
037 Shutdown: Gen phase seq. fail
038 Shutdown: Low Engine Speed
039 Shutdown: High Engine Speed
040 Shutdown: not used
041 Shutdown: not used
042 Shutdown: not used
043 Shutdown: not used
044 Shutdown: not used
045 Shutdown: not used
046 Shutdown: Communication lost
047 Shutdown: not used
048 Load Dump: Digital Input_0
049 Load Dump: Digital Input_1
050 Load Dump: Digital Input_2
051 Load Dump: Digital Input_3
052 Load Dump: Digital Input_4
053 Load Dump: Digital Input_5
054 Load Dump: Digital Input_6
055 Load Dump: Digital Input_7
No: FUNCTION
056 Load Dump: not used
057 Load Dump: not used
058 Load Dump: not used
059 Load Dump: not used
060 Load Dump: not used
061 Load Dump: Gen Reverse Power
062 Load Dump: Gen Excess Power
063 Load Dump: Alternator Overcurr.
064 Load Dump: not used
065 Load Dump: not used
066 Load Dump: not used
067 Load Dump: not used
068 Load Dump: not used
069 Load Dump: not used
070 Load Dump: not used
071 Load Dump: not used
072 Load Dump: not used
073 Load Dump: not used
074 Load Dump: not used
075 Load Dump: not used
076 Load Dump: not used
077 Load Dump: not used
078 Load Dump: not used
079 Load Dump: not used
080 Warning: Digital Input_0
081 Warning: Digital Input_1
082 Warning: Digital Input_2
083 Warning: Digital Input_3
084 Warning: Digital Input_4
085 Warning: Digital Input_5
086 Warning: Digital Input_6
087 Warning: Digital Input_7
088 Warning: Synchronization Fail
089 Warning: Gen Under-Frequency
090 Warning: Gen Over-Frequency
091 Warning: High Battery Voltage
092 Warning: Low Fuel Level
093 Warning: High Oil Temp. Mea.
094 Warning: High Temp. Measured
095 Warning: Low Oil Pressure Mea.
096 Warning: Mains Phase Seq. Fail
097 Warning: not used
098 Warning: Charge Failure
099 Warning: Low Battery Voltage
100 Warning: AVR Control Fail
101 Warning: GOV Control Fail
102 Warning: Low Engine Speed
103 Warning: High Engine Speed
104 Warning: Mains Fail at Parallel
105 Warning: Mains Reverse Power
106 Warning: Mains Freq. Failure
107 Warning: No Mains Frequency
108 Warning: ROCOF (df/dt) Failure
109 Warning: Vector Shift (df/dt) Fail
110 Warning: Communication lost
111 Warning: not used
