System Connections
6 BC 9xx0 Cradle
System Connections
BC9x80 models - Ethernet Connection
The BC9x80 models contain an Ethernet connector and a power supply con-
nector. A multi-interface connector is also available (intended for service pur-
poses only).
Ferrite Clamp Filter
CAUTION
Connections should always be made with power off!
CAUTION
Ensure the cable is plugged into the correct connector. Forcing
an Ethernet cable into the Multi-interface connector or forcing a
Multi-interface cable into the Ethernet connector could damage
the unit.
If a Ferrite Clamp filter is included in the package, mount it on
the Ethernet cable as shown, about 5 cm from the plug.
