5 TECHNICAL FEATURES
DS2100-XXX0 DS2100-XXX4 Testarossa™
Standard
Resolution
High
Resolution
Standard
Resolution
High
Resolution
ELECTRICAL FEATURES
Power
Supply voltage 10 to 30 Vdc
Power consumption max. 3 W 4 W
Serial Interfaces
(depends on model)
Main RS232; RS485 Full-duplex / Half-duplex;
20 mA C.L. (only with INT-22 accessory)
Auxiliary RS232
Baud Rates 150 to 115200
Inputs
External Trigger (optocoupled NPN or PNP)
Voltage max. 30 Vdc
Input current max. 25 mA
Outputs
(except X3X0 models)
OUT1, OUT2 (optocoupled)
V
CE
max.
40 Vdc
Collector current max. 40 mA continuous; 130 mA pulsed
V
CE
saturation 1V at 10 mA max.
Power dissipation max.
90 mW at 40 °C (Ambient temp.)
OPTICAL FEATURES
Light source Semiconductor laser diode
Wave length
(Note 1)
630 to 680 nm
Ambient light immunity Complete immunity
Safety class Class 2 - IEC 825-1; Class II - CDRH
READING FEATURES
(Note 2)
Scan rate 350 scans/sec. 800 scans/sec. 600 scans/sec.
Reading distance see diagrams in par. 3.4
Maximum resolution mm (mils) 0.20 (8) 0.15 (6) 0.20 (8) 0.12 (5)
Aperture angle 60°
USER INTERFACE
LED indicators Laser On, Good Read, External Trigger,
Data TX / Power On
