DX8200 CONTROLLER
QUICK GUIDE
4
Model Description:
DX8200 Controller - X 0 X X
Laser Number:
2 = Double laser
3 = Triple laser
Optical Resolution:
0 = Standard resolution
1 = High resolution
Power supply:
0 = VDC
1 = VAC
Technical Features:
ELECTRICAL FEATURES
(Note 1)
OPTICAL FEATURES
Models X0X1 Models X0X0 Light Source
Up to 3 VLDs
Supply Voltage
85 – 264 VAC 20 - 30 VDC
Wavelength
630 to 680 nm
Current Consumption Safety Class
Class 2-EN 60825-1;
maximum 0.4 ~ 0.2 A 1.5 ~ 1.0 A
Class II-CDRH
Light Receiver
Avalanche photodiode
Communication
Main (isolated) Baud Rate
Laser Control
Security system to turn laser
off in case of motor slow down
Interfaces
RS232
READING FEATURES
RS485 full-duplex 1200 to 115200
Scan Rate
500-1000 scans/s
RS485 half-duplex
20 mA C.L.
(INT-60)
19200
USER INTERFACE
Auxiliary
LED Indicators
Power ON
RS232
Encoder
Other
Good Read
Lonworks network 1,25 Mb/s
TX Data
Inputs
Network (Lonworks)
Ext. Trigger, Encoder,
2 aux. digital inputs
(optocoupled NPN or PNP)
Outputs
3 software
programmable digital
outputs
(optocoupled open emitter,
open collector)
SOFTWARE FEATURES ENVIRONMENTAL FEATURES
Interleaved 2/5
Readable Code
Symbologies
Code 39 standard
Operating
Temperature
0° to +50 °C (+32 to +122 °F)
Codabar
Code 128/EAN 128
Storage
Temperature
-20° to +70 °C (-4° to +158 °F)
Code 93 (standard & full ASCII)
Humidity
90% non condensing
EAN/UPC
Vibration
Resistance
EN 60068-2-6 test FC
1.5 mm @ 5 to 9.1 Hz;
0.5 G @ 9.1 to 150 Hz;
2 hours on each axis
Code Selection
Up to 10 codes during one
Shock Resistance
EN 60068-2-27 test EA
reading phase
15 G; 11 ms;
Headers and
Up to 128-byte headers and 3 shocks on each axis in each
Terminators
128-byte terminators
direction
Operating Modes
Pack-Track™
Protection Class
IP54
Config. Mode
Genius™ utility program
PHYSICAL FEATURES
Dimensions mm
576 x 513 x 150 mm
(inch)
(22.7 x 20.2 x 5.9 in)
Parameter Storage
Non-volatile internal FLASH
Weight
about 22 Kg (48.5 lbs.)
Note 1: The features given are typical at 25 °C ambient temperature (if not otherwise indicated).
