DS6300 ETHERNET MODEL
14
SOFTWARE FEATURES ENVIRONMENTAL FEATURES
Interleaved 2/5
Operating
Readable Codes
Code 39 standard
Temperature
0° to +40 °C
(+32 to +104 °F)
Codabar
Code 128
Storage Temperature
-20° to +70 °C
(-4° to +158 °F)
EAN 128
Humidity
90% non condensing
Code 93 (Standard & Full ASCII)
Ambient Light
EAN/UPC (including Add-on 2 and
Immunity
3500 lux
Add-on 5)
Vibration Resistance
14mm @ 2 to 10Hz
Code Selection
Up to 10 codes during one reading IEC 68-2-6 test FC 1.5 mm @13 to 55 Hz
phase
2 g @ 70 to 200 Hz
2 hours on each axis
Headers and
Up to 128-byte headers and128- Shock Resistance
30 g; 11 ms
Terminators
byte terminators
IEC 68-2-27 test EA 3 shocks on each axis
Operating
Protection Class
Modes
On Line, Automatic, Test
Config. Mode
Genius™ utility program
IP50
Param. Storage
Non-volatile internal FLASH
PHYSICAL FEATURES
Std Models Oscill. Mirror
Dimensions mm
(inch)
110x113x99
(4.33x4.45x3.9)
113x180x104.5
(4.45x7.08x4.11)
Weight
1.5 kg (3.3 lb) 2.0 kg (4.4 lb)
Accessories:
Name Description Part Number
CAB-6011 Cable to C-BOX100 1 m 93A051221
CAB-6012 Cable to C-BOX100 2 m 93A051222
CAB-6015 Cable to C-BOX100 5 m 93A051223
C-BOX 100 Passive connection box 93ACC1510
INT-30 20 mA C.L. interface board for C-BOX 100 93A151022
GFC-60 90° mirror 93A201100
GFC-600 90° mirror close distance 93A201102
GFX-60 X-pattern mirror 93ACC1730
PWR-120 Power unit 110/230 V AC - 24 V DC 93ACC1530
BTK-6000 Terminator kit (5 pcs) 93ACC1710
PG6002 Single unit power supply – US 93ACC1718
PG6001 Single unit power supply – UK 93ACC1719
PG6000 Single unit power supply – EU 93ACC1720
FBK-6000 Fast bracket kit (2 pcs) 93ACC1721
US-60 Mounting bracket kit (5 pcs) for multisided stations 93ACC1729
PH-1 Photocell kit - PNP 93ACC1791
MEP-543 Photocell kit – NPN 93ACC1728
OEK-2 Optical encoder (10 m cable + spring) 93ACC1770
OEK-1 Optical encoder kit + 10 m cable 93ACC1600
Electrical Connections:
The DS6300 Ethernet reader provides a 26-pin male D-sub connector for connection to power supply and
input/output signals.
An Ethernet connector is used for connection to the remote Host (for ex. Remote PC connected via Internet),
while a local Lonworks 9-pin female connector connects the Ethernet master to the first slave reader of the
system.
The details of the connector pins are indicated in the following table:
