Datalogic DS6300

DS6300 ETHERNET MODEL
17
Local Lonworks Network
Fieldbus Small Synchronized Network
* P.S. (Presence Sensor) connected to External Trigger/PS input.
** C-BOX 100 modified to accept scanner power.
*** The Slave scanners are Master/Slave models, which allow Lonworks network propagation.
**** Encoder connected to IN2/ENC input.
Remote Host
Master
C-BOX 100**
PWR-240
CAB-610X
P.S.*
Slave 2***
Fieldbus
Network
Slave 1***
CAB-610X
CAB-60XX
Encoder****
CAB-63XX
CAB-610X
CAB-610X
BTK-6000
Slave 3***Slave 5***
Slave 4***
CAB-610X
CAB-63XX
