DS8100A-3002 QUICK GUIDE
3
DS8100A-3002 GENERAL VIEW
Figure A
Laser Beam Output Window
1
Figure B
Programming Keypad
1
Phase On LED (Yellow)
3
Power On LED (Green)
2
TX Data LED (Green)
5
Network LED (Red)
6
Encoder LED (Yellow)
4
LCD Display
7
Figure C
Lonworks 17-pin Male Connector
1
Lonworks 17-pin Female Connector
2
1
1
2
7
1
2 3
4 5 6
