TECHNICAL FEATURES
ELECTRICAL FEATURES
Supply Voltage 20 to 30 Vdc
Power Consumption 1.0 to 0.67 A; 20 W typical
1.5 to 1.0 A; 30 W Max. (including startup current)
Communication Interfaces
Auxiliary Baud Rate
RS232 1200 to 115200
Other
Lonworks 1.25 Mb/s
OPTICAL FEATURES
Light Receiver Avalanche photodiode
Safety Class 630 to 680 nm
Wavelength Class 2-EN 60825-1; Class II-CDRH
Laser Control Security system to turn laser off in case of motor slow down
READING FEATURES
Scan Rate ≤ 1000 scans/s
Max. Resolution
Max. Read. Distance
Max. Read. Width
Max. Depth of Field
(see reading diagrams)
USER INTERFACE
LCD Display 2 lines by 20 characters LCD
Keypad 3 keys
LED Indicators Power ON (green)
Phase ON (yellow)
Encoder (yellow)
TX Data (green)
Network (red)
SOFTWARE FEATURES
Readable Codes Interleaved 2/5
Code 39 Standard
Codabar
Code 128
GS1-128 (ex EAN 128)
Code 93 (standard & full ASCII)
EAN/UPC (including Add-on 2 and Add-on 5)
GS1 DataBar (including Limited and Expanded)
Code Selection Up to 10 codes during one reading phase
Operating Modes PackTrack™
Configuration Mode Genius™ utility program
Parameter Storage Non-volatile internal FLASH
ENVIRONMENTAL FEATURES
Operating Temperature 0° to +50 °C (+32 to +122 °F)
Storage Temperature 20° to +70 °C (-4° to +158 °F)
Humidity -90% non condensing
Vibration Resistance
EN 60068-2-6
14 mm @ 2 to 10 Hz; 1.5 mm @ 13 to 55 Hz
2 g @ 70 to 200 Hz; 2 hours on each axis
Shock Resistance
EN 60068-2-27
30 g; 11 ms
3 shocks on each axis
Protection Class
EN 60529
IP65*
PHYSICAL FEATURES
Dimensions mm (inch) 217 x 173 x 127 (8.54 x 6.79 x 4.98)
Weight 5 Kg (11 lbs.)
* IP65 cables and connectors required (CAB-850x or BTK-8500).
