DX8200A QUICK GUIDE
10
Local Lonworks Networks
Large Synchronized Network with DX8200A and DS8100A Scanners
Large Synchronized Network Reading Station
Extended I/O
Host
HUB
ETHERNET
SC6000
AUX
CAB-SC6003
CAB-SC6003
Power/Net
VAC INPUT
CAB-SC6103
Cable
PWO
LONWORKS
ENCODER
PS
PS Aux
CAB-810x
CAB-810x
CAB-810x
CAB-810x
CAB-810X
up to 3
scanners
per
branch
BTK8100
Bus Return
DX8200A
DX8200A
DX8200A
DS8100A
DS8100A
DS8100A
DS8100A
CAB-810x
CAB-810x
up to 4
scanners per
branch
BTK8100
Bus Return
Conveyor
SC6000
