DX8200A QUICK GUIDE
8
Connectivity:
Examples of the most common system layouts are shown in this section, for additional layouts refer to the
Reference Manual.
Point-to-Point Layout
* P.S. (Presence Sensor) connected to External Trigger/PS input.
Point-to-Point for Standard DC Models
* P.S. (Presence Sensor) connected to External Trigger/PS input.
** C-BOX 100 modified to accept scanner power
Point-to-Point for Standard AC Models
Standard
Presence
Sensor*
C-BOX 100
Local Host
CAB601X
PWR-120
Standard
Presence
Sensor*
C-BOX 100**
Local Host
CAB601X
110 - 230 Vac
