1.4 REPLACING THE HAND STRAP
To remove the hand strap, proceed as follows.
1. Unscrew the strap pivot to remove the upper end of the hand strap:
2. Lift the bottom of the hand strap to place the hook vertically:
3. Press on the upper sides of the hook to remove it:
4. Reverse the steps above to the insert new hand strap.
