Datalogic ELF User Manual

CONNECTIONS
31
3
3.6 WWAN CONNECTION
Elf GSM models enhance your connectivity solutions giving you an opening to an
international wireless infrastructure that is the global standard.
Elf uses the 850, 900, 1800 and 1900 MHz bands.
In order to use a WWAN Connection you have to install a SIM Card
∗
(see instructions
on par. 1.5).
In order to extend battery life, the GSM module is off by default. If
you need to have GSM working, the module must be powered on
using the Wireless Manager applet (see par. 4.6.6).
NOTE
Suspending the terminal powers off the GSM radio and drops the
connection. When the terminal resumes, if the connection was
managed by Microsoft Internet Explorer, it is automatically restored,
otherwise, the radio connection must be manually re-initialized.
NOTE
The GSM voice capability of this PDA has to be addressed to
occasional use, in well covered areas.
If the coverage is poor, the voice quality can be highly affected.
NOTE
∗
the SIM Card option is not available in 802.11 a/b/g radio and batch models

Datalogic ELF Specifications

General

Display diagonal	3.5 \
Display resolution	640 x 480 pixels
Display number of colors	65536 colors
Internal memory	0.256 GB
Internal memory type	-
Compatible memory cards	SD, SDHC
Built-in processor	PXA310
Processor frequency	0.624 GHz
Product color	Black
Phone function	No
Keyboard layout	Numeric
Image formats supported	BMP, JPG
Bundled software	Windows Mobile 6.5 + Mobile tools: Outlook, Word Mobile, Excel Mobile, PowerPoint Mobile, One Note Mobile & Internet Explorer Mobile 6.0
Data network	EDGE, GPRS, GSM, HSDPA
Bluetooth version	2.0+EDR
GSM bands supported	850, 900, 1800, 1900 MHz
Operating frequency	2400 - 5200 MHz
Wireless technology	WiFi
Rear camera resolution (numeric)	3 MP
Power supply	11.10 W
Power requirements	3.7V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 50 °C
Key benefits	27

Weight and Dimensions

Depth	42 mm
Width	157 mm
Height	81 mm
Weight	415 g
