Datalogic ELF User Manual

147
RADIO COMPLIANCE
In radio systems configured with PDAs and access points, the frequencies to be used
must be allowed by the spectrum authorities of the specific country in which the
installation takes place. Be absolutely sure that the system frequencies are correctly
set to be compliant with the spectrum requirements of the country.
The Radio modules used in this product automatically adapt to the frequencies set by
the system and do not require any parameter settings.
The TYPE field shows the correspondence between ELF™ types and radio modules:
TYPE: ABCDEE-FGH-IJJK-LMMMM
A: “0” if WWAN module is not present, “E” for GSM/GPRS/EDGE WWAN module, “U”
for UMTS/HSDPA WWAN module
B: “0” if GPS module is not present
C: “0” if IEEE 802.11 module is not present, “A” for IEEE 802.11 abg module, “G” for
IEEE 802.11 bg module, “N” for IEEE 802.11 abgn module
D: “0” if RFID module is not present.

Datalogic ELF Specifications

General

Display diagonal	3.5 \
Display resolution	640 x 480 pixels
Display number of colors	65536 colors
Internal memory	0.256 GB
Internal memory type	-
Compatible memory cards	SD, SDHC
Built-in processor	PXA310
Processor frequency	0.624 GHz
Product color	Black
Phone function	No
Keyboard layout	Numeric
Image formats supported	BMP, JPG
Bundled software	Windows Mobile 6.5 + Mobile tools: Outlook, Word Mobile, Excel Mobile, PowerPoint Mobile, One Note Mobile & Internet Explorer Mobile 6.0
Data network	EDGE, GPRS, GSM, HSDPA
Bluetooth version	2.0+EDR
GSM bands supported	850, 900, 1800, 1900 MHz
Operating frequency	2400 - 5200 MHz
Wireless technology	WiFi
Rear camera resolution (numeric)	3 MP
Power supply	11.10 W
Power requirements	3.7V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 50 °C
Key benefits	27

Weight and Dimensions

Depth	42 mm
Width	157 mm
Height	81 mm
Weight	415 g
