1 ELF™
132
5
READING OPTIONS
LASER CHARACTERISTICS
SCANNING RATE 104 ± 12 scan/sec
MINIMUM RESOLUTION 0.10 mm / 4 mils
DEPTH OF FIELD
5 to 64 cm (2 to 25 in), depending on bar code
density
SKEW ANGLE ± 50°
PITCH ANGLE ± 65°
AIMING LASER VLD, wavelength 630~680 nm
BAR CODES
GS1 Databar, EAN/UPC, Code 39, 2/5 Codes,
Plessey, Codabar, Code 128, EAN128, MSI,
Code 93, Code 11
LASER CLASSIFICATION VLD - Class 2/II EN 60825-1/CDHR
LED CLASSIFICATION IEC Class 1M
IMAGER CHARACTERISTICS
SCANNING RATE 60 frames/sec maximum
MINIMUM RESOLUTION Linear codes at 3 mils; 2D codes at 5 mils
AIMING LASER VLD, wavelength 645~665 nm
BAR CODES
UPC A, UPC E, EAN 8, EAN 13, Interleaved 2 of
5, Code 39, Code 39 Full ASCII, Codabar, Code
128, EAN 128, Code 93, MSI, PDF417, Micro
PDF, DataMatrix, QR, GS1 Databar, Aztec,
Maxicode, POSTNET, PLANET, Japan Post,
Australia Post, KIX Code, Royal Mail RM4SCC,
USPS 4CB, UPU FICS
LASER CLASSIFICATION CDRH/IEC Class II
LED CLASSIFICATION IEC Class 1M
ILLUMINATION SYSTEM LEDs 620~630 nm

Datalogic ELF Specifications

General

Display diagonal	3.5 \
Display resolution	640 x 480 pixels
Display number of colors	65536 colors
Internal memory	0.256 GB
Internal memory type	-
Compatible memory cards	SD, SDHC
Built-in processor	PXA310
Processor frequency	0.624 GHz
Product color	Black
Phone function	No
Keyboard layout	Numeric
Image formats supported	BMP, JPG
Bundled software	Windows Mobile 6.5 + Mobile tools: Outlook, Word Mobile, Excel Mobile, PowerPoint Mobile, One Note Mobile & Internet Explorer Mobile 6.0
Data network	EDGE, GPRS, GSM, HSDPA
Bluetooth version	2.0+EDR
GSM bands supported	850, 900, 1800, 1900 MHz
Operating frequency	2400 - 5200 MHz
Wireless technology	WiFi
Rear camera resolution (numeric)	3 MP
Power supply	11.10 W
Power requirements	3.7V
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 50 °C
Key benefits	27

Weight and Dimensions

Depth	42 mm
Width	157 mm
Height	81 mm
Weight	415 g
