Configuring the Interface
QUICK REFERENCE GUIDE
15
CONFIGURING THE INTERFACE
Scan the appropriate programming bar code to select the
interface type for your system.
NOTE: Unlike some other programming features
and options, interface selections require that you
scan only one programming bar code label. DO
NOT scan an ENTER/EXIT bar code prior to scan-
ning an interface selection bar code.
Some interfaces require the scanner to start in
the disabled state when powered up. If additional
scanner configuration is desired while in this
state, pull the trigger and hold for 5 seconds. The
scanner will change to a state that allows pro-
gramming with bar codes.
RS-232
Select RS232-STD
RS-232 standard interface
Select RS232-WN
RS-232 Wincor-Nixdorf
Select RS-232 OPOS
RS-232 for use with OPOS/UPOS/JavaPOS
IBM
Select IBM - P9B
IBM-46xx Port 9B reader interface
To Next Page
