Technical Features
16 Gryphon™ L GD4300
Technical Features
Item Description
Physical Characteristics
Color
White/Grey
Bl
ack/Grey
Dimensions
Height 7.1” / 181mm
L
ength 3.9” / 100mm
Width 2.8” / 71mm
Weight (without cable) Approximately 6.0 ounces/169 g
Electrical Characteristics
V
oltage & Current
GD4330 model:
In
put current at 5V±5% = 260 mA (max)
2.5 mA (USB suspend)
Standby (typical) ≤ 30mA
GD4310 model:
Input Power = 1.2W max in the 4.5÷14V range
2.5 mA (USB suspend)
Standby (typical): 30mA @5V, except 90mA @5V in IBM 46xx
Performance Characteristics
Light
Source 650nm Class 2 Laser
Pitch (Yaw) ± 50°
Skew ± 65°
Roll (Tilt) ± 35°
Scan Angle 47° (normal) or 35° (narrow)
Depth of Field
(T
ypical)
5 mil - 1.4" to 6.22" (3,6cm to 15,8cm)
13 mil* – 0.87" to 18.7" (2,2cm to 47,5cm)
20 mil – up to 27.1" (to 69cm)
Minimum Element Width 4 mil
Print Contrast Minimum
(T
ypical)
15% minimum reflectance
Decode Capability
UPC/EAN/JAN, P2 /P5 add-ons; Code 39; Code 32; Code 128;
C
ode 128 ISBT; Code 128 add-ons; Interleaved 2 of 5; Standard
2 of 5; Code 11; Codabar; EAN 128; GS1 DataBar™ Omnidirec-
tional, GS1 DataBar™ Limited, GS1 DataBar™ Expanded, Code 4,
Code 5, Follett 2 of 5.
