LED and Beeper Indications
18 Gryphon™ L GD4300
LED and Beeper Indications
The reader’s beeper sounds and its LED illuminates to indicate
various functions or errors on the reader. A “Green Spot” also
lights to indicate a good read. The tables below list these indica-
tions. One exception to the behaviors listed in the tables is that the
reader’s functions are programmable, and may or may not be
turned on. For example, certain indications, such as the power-up
beep can be disabled using programming barcode labels. Reference
the PRG for a more detailed list.
Indication LED Beeper
Power-up
LED flashes/blinks on
power-up, however, this may
be too rapid to view. With a
USB interface, the LED blinks
until enumeration with the
host is completed.
Reader beeps four times at
highest frequency and vol-
ume upon power-up.
Good Read
LED behavior for this indica-
tion is configurable using the
PRG.
One beep at current fre-
quency, volume,
mono/bi-tonal setting upon
a successful label scan.
ROM Failure 200ms on / 200ms off
Reader sounds one error
beep at highest volume for
200 mS.
Limited Scanning
Label Read
N/A
Reader 'chirps' six times at
the highest frequency and
current volume.
Reader Disabled
The LED blinks continuously
100ms on / 900 ms off
N/A
