Regulatory Information
20 Gryphon™ L GD4300
Regulatory Information
All models are designed to be compliant with rules and regulations
in locations they are sold and will be labeled as required.
Any changes or modifications to equipment not expressly ap-
proved by Datalogic could void the user's authority to operate the
equipment.
Power Supply
This device is intended to be connected to a UL Listed/CSA Cer-
tified computer which supplies power directly to the reader or else
be supplied by UL Listed/CSA Certified Power Unit marked
“Class 2” or LPS power source rated 4.5-14 minimum 600mA for
GD4310 or rated 5.2V minimum 600mA for GD4330, which
supplies power directly to the reader via the power connector of the
cable.
Use only authorized power supplies supplied by your Datalogic re-
seller. The use of any other power supplies can damage the reader
and void your warranty.
For USB Power Off Terminal applications, attach to
USB 1.0, 1.1 or 2.0 host device only.
Atencíon
Características de la
fuente de alimentación
eléctrica.
Entrada:
100 - 240 Vca
min 400mA 50-60 Hz
Salida:
12VDC, m
á
x1500mA
(-)Negativo al centro
Entrada:
100 - 240Vca
min 350 mA 50-60 Hz
Salida:
m
á
x 5,2VDC, m
á
x 2500mA
(-)Negativo al centro
Utilice en su red solo fuentes certificadas en Argentina.
El uso de fuentes de alimentación no compatibles puede resultar en riesgo
de incendio o de choque eléctrico para el usuario.
