READING DIAGRAMS
GRYPHON™ D130
0
5
10 15 20 25 30 35
-15
-10
-5
0
5
10
15
Reading diagram at 25 °C and 300 lux ambient lighting
Reading Zones (10° skew angle)
(cm)
EAN13 M=1
0.33 mm
(13 mils)
CODE 39
0.50 mm
(20 mils)
0.13 mm
(5 mils)
GRYPHON™ D130-LR
0 5 10 15 20 25 30 35
-15
-10
-5
0
5
10
15
Reading diagram at 25 °C and 300 lux ambient lighting
Reading Zones (10° skew angle)
(cm)
CODE 39
0.13 mm
(5 mils)
40 45 50 55
EAN13 M=1
0.33 mm
(13 mils)
CODE 39
0.50 mm
(20 mils)
