USING GRYPHON™ DX30 READERS
Gryphon™ guns automatically scan barcodes at a distance.
Simply aim and pull the trigger. Code scanning is performed
along the center of the light bar emitted from the reading
window. This bar must cover the entire code.
Successful scanning is obtained by tilting the scanner with
respect to the barcode to avoid direct reflections which impair
the reading performance, see the figure above.
Successful reading is signaled by an audible tone plus a
good-read green spot.
CONNECTIONS
RS232
USB
(if required)
