Symbologies
5-42 Magellan
®
1400i
Interleaved 2 of 5 — continued
Interleaved 2 of 5 Length 1, Length 2 Programming Instructions
1. Scan the START barcode.
2. Scan either the Set Length 1 or Set Length 2 barcode.
3. Turn to
Appendix C, Alpha-Numeric Pad and scan the three digits (zero padded) represent-
ing the length in decimal notation
.
4. Scan the END barcode.
NOTE
For Interleaved 2 of 5 barcodes, lengths must be
an even number. Additionally, all check and data
characters are included in the length calcula-
tions.
START / END
PROGRAMMING BAR CODES
DEFAULT SETTING FOR THIS FEATURE: 006
Set Length 1
Set Length 2
DEFAULT SETTING FOR THIS FEATURE: 050
