MATRIX 410™ QUICK GUIDE
20
TECHNICAL FEATURES
ELECTRICAL FEATURES
Power
Supply Voltage 10 to 30 Vdc
Consumption 0.8 to 0.27 A, 8 W max.; 0.5 to 0.17 A, 5 W typical
Communication Interfaces
Main
- RS232
- RS485 full-duplex
- RS485 half-duplex
2400 to 115200 bit/s
2400 to 115200 bit/s
2400 to 115200 bit/s
Auxiliary - RS232 2400 to 115200 bit/s
ID-NET™ Up to 1MBaud
Ethernet (Ethernet Models only) 10/100 Mbit/s
Inputs
Input 1(External Trigger) and Input 2 Opto-coupled and polarity insensitive
Max. Voltage 30 Vdc
Max. Input Current 10 mA
Outputs
Output 1 and Output 2 Opto-coupled
VOut (ILoad = 0 mA) Max.
30 Vdc
VOut (ILoad = 10 mA) Max.
1.8 Vdc
PD = VOut ILoad Max.
170 mW
OPTICAL FEATURES
4xx-xxx models 6xx-xxx models
Image Sensor CMOS CCD
Image Format SXGA (1280x1024) UXGA (1600x1200)
Frame Rate 27 frames/sec. 15 frames/sec.
Pitch
 35°
Tilt 0° - 360°
Lighting System Internal or External Illuminator (accessories)
LED Safety Class Class 1 to EN60825-1
ENVIRONMENTAL FEATURES
Operating Temperature
0 to 50 C (32 to 122 °F) *
Storage Temperature
-20 to 70 C (-4 to 158 °F)
Max. Humidity 90% non condensing
Vibration Resistance 14 mm @ 2 to 10 Hz; 1.5 mm @ 13 to 55 Hz;
EN 60068-2-6 2 g @ 70 to 200 Hz; 2 hours on each axis
Bump Resistance 30g; 6 ms;
EN 60068-2-29 5000 shocks on each axis
Shock Resistance 30g; 11 ms;
EN 60068-2-27 3 shocks on each axis
Protection Class
EN 60529
IP67 **
PHYSICAL FEATURES
Dimensions 125 x 65 x 86 mm (4.92 x 2.56 x 3.39 in.) with lens cover
Weight 482 g. (17 oz.) with lens and internal illuminator
Material Aluminium
* high ambient temperature applications should use metal mounting bracket for heat dissipation
** when correctly connected to IP67 cables with seals and the Lens Cover is correctly mounted.
