Datalogic PowerScan M8300 Quick Reference Guide

Charging the Batteries
4 PowerScan® M8300
CHARGING THE BATTERIES
Once the BC-80X0/C-8000 is powered, you can charge the reader's batteries.
Place the PowerScan
®
M8300 into the BC-80X0 cradle or the C-8000 battery charger.
The "Reader" LED on the cradle/battery charger turns red.
The battery is completely charged when the "Reader" LED on the cradle/battery
charger turns green.
To change the batteries, unscrew the retaining screw and extract the battery pack
from the reader handle. Then, insert the new battery pack into the reader handle and
tighten the screw. (See the following figures).
Figure 1 – Changing the Batteries
Do not incinerate, disassemble, short terminals or expose to high tem-
perature. Risk of fire, explosion. Use specified charger only. Risk of explo-
sion if the battery is replaced by an incorrect type. Dispose of the
batteries as required by the relevant laws in force.
WARNING
1
2

Datalogic PowerScan M8300 Specifications

General

Scanner type	1D
Maximum range	30 m
Read rate (max)	40 reads/s
Yaw reading angle	-60 - 60 °
Decoding standards	GS1 DataBar, Code 16K, Code 49, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional
Tilt reading angle	-20 - 20 °
Pitch reading angle	-55 - 55 °
Operating time	240 min
Dimensions (WxDxH)	114 x 69 x 210 mm
Bluetooth	No
Operating frequency	910 MHz
Input voltage	10 - 30 V
Battery capacity	2150 mAh
Power requirements	0.33 - 1A
Number of reads per charge	60000
Certification	IP64, China RoHS, EU RoHS, CDRH Class II, IEC 60825-1 Class 2
Keys quantity	3 keys
Product color	Black, Yellow
LED indicators	Charging, Power
Display resolution	32 x 96 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Weight	393 g
