Decoded scanners can be programmed to decode extremely poor qual-

ity bar codes by activating advanced Quadralogic II™ Decoding. To

select this feature, see the Programming Guide.

Scanner programming can also be performed using your PC and the

Configurator Express™ On-Screen Programming Kit.

Figure 11. Scanner Labeling and Nomenclature

NOTE

Information about manuals, kits and programming

software for this product are available at our web-

site. See the back cover for our web address.

1. Trigger 4. Tether Hook

2. Scan Window 5. Yellow LED

3. Green LED 6. Battery
