Technical Features
Quickscan Lite QW2400
Item Description
Electrical Features
Power Supply
RS-232 interface
5 Vdc
 10%
Consumption:
Operating (Typical): 170 mA @ 5 VDC
Standby/Idle (Typical): 90 mA @ 5 VDC
Max. Scan Rate 50 frames/sec
Reading Indicators Top Illumination, Good Read Spot, Beep
Optical Features
Optical Format 1/7.5"
Active Imager Size 1.97 mm (H) x 1.49 mm (V)
Active Pixels 640 H x 480 V
Illumination System
LED source
White Emission (wavelength = 350-770 nm)
IEC 62471 – Exempt Risk Group
Aiming System
LED source
Blue emission (wavelength = 470nm)
Pulsed source: pulsed with 10 ms duration,50%
duty cycle
IEC 62471 – Risk Group 1
Ambient Light Up to 92000 lux
Tilt Tolerance 0° - 360°
Pitch Tolerance ± 65°
Skew Tolerance ± 65
Field of View 48° H x 37° V
DOF
Depth of Field
(Typical)
Code 39: 5 mils: 0.5 to 12.5 cm / 0.2 to 4.9 in
EAN/UPCA: 13 mils: 0.5 to 30.0 cm / 0.2 to 11.8
in
PDF417: 6.6 mils: 1.0 to 9.5 cm / 0.4 to 3.7 in
Data Matrix: 10 mils: 1.0 to 9.5 cm / 0.4 to 3.7 in
QR: 20 mils: 1.0 to 14 cm / 0.4 to 5.5 in
Max. Resolution Code 39, 4 mil
PCS (Datalogic Test
Chart)
minimum 20%

Datalogic QuickScan Lite QW2400 Specifications

General

Brand	Datalogic
Model	QuickScan Lite QW2400
Category	Barcode Reader
Language	English
