Connecting the Base Station
6 QuickScan™ QM2400
Figure 4. Connecting to the Host
Power Connection —
Plug the AC Adapter into an approved AC
wall socket with the cable facing downwards (as shown in
Figure 3) to prevent undue strain on the socket.
System and Network Layouts
Stand Alone Layout
Figure 5. Reader Layout
U
S
B
I
B
M
K
e
y
b
o
a
r
d
W
e
d
g
e
W
a
n
d
or...
or...
or...
Reader
Base Station
Host
