Technical Specifications
Quick Reference Guide 29
Technical Specifications
The following table contains Physical and Performance Char-
acteristics, User Environment and Regulatory information.
Physical Characteristics
Color White or Black
Dimensions
Height 6.4”/163 mm
Length 3.6”/91 mm
Width 1.6”/41 mm
Weight (without cable)
Approximately
200 g (reader)
230 g (base charger)
Electrical Characteristics
Battery Type Li-Ion battery pack
Typical charge time for
full charge from full
discharge
6 hours with Host Power through the
micro USB cable connection
4 hours with Base and 12V external
power supply adapter
a
Max 22 hours with Base and Host
power (in this case no supply adapter
is needed)
a
Operating autonomy
(continuous reading)
30,000 reads
(typical)
Cradle consumption
and DC input supply
range
Volt 4.75-14 VDC; Power <8W
b
;
Imax 500mA when in host/bus pow-
ered mode
b
.
