Datalogic QuickScan QM2430 User Manual

Technical Specifications
30 QuickScan™ QM2400
Performance Characteristics
Light Source LEDs
Roll (Tilt) Angle
c
Up to ± 180°
Pitch Angle
c.
± 40°
Skew (Yaw) Angle
c.
± 40°
Field of View 40° H x 26° V
a. Charge Times are much lower when battery is within daily typical operating
condition.
b. Typical input current measured under factory default configuration.
c. Based on ISO 15423 specifications.
Depth of Field (Typical)
a
a. 13 mils DOF based on EAN. All other 1D codes are Code 39. All labels grade
A, typical environmental light, 20°C, label inclination 10°
Symbology
Code 39
5mil: 0.2" - 5.9" (0.5 - 15cm)
10mil: 0" - 8.7" (0 - 22cm)
20mil: up to 16" (40cm)
EAN
7.5mil: 0" - 5.9" (0 - 15cm)
13mil: 0.2" - 13.8" (0.5 - 35cm)
PDF-417
6.6mil: 0.39" - 5.1" (1.0 - 130cm)
10mil: 0" - 8.3" (0 - 21cm)
15mil: 0.2" - 9.5" (0.5 - 24cm)
DataMatrix
10mil: 0.39" - 5.1" (1.0 - 13 cm)
15mil: 0" - 7.1" (0 - 18cm)
QR Code
10mil: 0.2" - 5.1" (0.5 - 13cm)
15mil: 0" - 7.1" (0 - 18cm)
Minimum
Element Width
Standard Range:
1D Min Resolution = 4 mil
PDF-417 Min Resolution = 5 mil
Datamatrix Min Resolution = 7.5 mil
