Charging the Batteries
8 QuickScan™ QM2400
Charging the Batteries
To charge the battery, simply insert the QuickScan reader into
the base. When the scanner is fully seated in the cradle, it will
sound a “chirp” to indicate that the cradle has detected the
scanner connection.
The LEDs on the base (shown in Table 1 on page 7) will indi-
cate the status of the battery.
Alternatively, the battery can be charged by connecting the
reader directly to a host through the micro-USB connector
available in the bottom of the handle, as shown below.
NOTE
Before using the battery, read “Battery Safety” in
the Regulatory Addendum for this manual. Data-
logic recommends annual replacement of
rechargeable battery packs to ensure maximum
performance.
