LED and Beeper Indications
Quick Reference Guide 33
LED and Beeper Indications
The reader’s beeper sounds and its LED illuminates to indi-
cate various functions or errors on the reader. An optional
“Green Spot” also performs useful functions. The following
tables list these indications. One exception to the behaviors
listed in the tables is that the reader’s functions are program-
mable, and so may or may not be turned on. For example, cer-
tain indications such as the power-up beep can be disabled
using programming bar code labels.
Indication Description LED Beeper
Power-up
Beep
The reader is in
the process of
powering-up.
N/A
Reader beeps
four times at
highest fre-
quency and vol-
ume upon
power-up.
Good Read
Beep
A label has been
successfully
scanned by the
reader.
LED behavior for
this indication is
configurable via
the feature
“Good Read:
When to Indi-
cate”
(see the PRG for
information.)
The reader will
beep once at
current fre-
quency, volume,
mono/bi-tonal
setting and
duration upon a
successful label
scan.
ROM Failure
There is an error
in the reader's
software/pro-
gramming
Flashes
Reader sounds
one error beep
at highest vol-
ume.
Limited
Scanning
Label Read
Indicates that a
host connection
is not estab-
lished when the
IBM or USB inter-
face is enabled.
N/A
Reader 'chirps'
six times at the
highest fre-
quency and cur-
rent volume.
Reader
Active Mode
The reader is
active and ready
to scan.
The LED is lit
steadily
a
N/A
Reader
Disabled
The reader has
been disabled by
the host.
The LED blinks
continuously
N/A
