LED and Beeper Indications
34 QuickScan™ QM2400
a Except when in sleep mode or when a Good Read LED Duration other than
00 is selected
Programming Mode
- The following indications ONLY occur when
the reader is in Programming Mode.
Green Spot
a
flashes
momentar-
ily
Upon successful
read of a label,
the software
shall turn the
green spot on for
the time specified
by the configured
value.
N/A N/A
Indication Description LED Beeper
Label Program-
ming Mode Entry
A valid program-
ming label has
been scanned.
LED blinks
continu-
ously
Reader sounds
four low fre-
quency beeps.
Label Program-
ming Mode Rejec-
tion of Label
A label has been
rejected.
N/A
Reader sounds
three times at
lowest fre-
quency and
current vol-
ume.
Label Program-
ming Mode
Acceptance of
Partial Label
In cases where
multiple labels
must be scanned
to program one
feature, this indi-
cation acknowl-
edges each
portion as it is
successfully
scanned.
N/A
Reader sounds
one short beep
at highest fre-
quency and
current vol-
ume.
Label Program-
ming Mode
Acceptance of
Programming
Configuration
option(s) have
been successfully
programmed via
labels and the
reader has exited
Programming
Mode.
N/A
Reader sounds
one high fre-
quency beep
and 4 low fre-
quency beeps
followed by
reset beeps.
Label Program-
ming Mode Can-
cel Item Entry
Cancel label has
been scanned.
N/A
Reader sounds
two times at
low frequency
and current
volume.
Indication Description LED Beeper
