WEDGE READER CONFIGURATION
Read the RESTORE DEFAULT
code, then read the interface
selection code for your application.
RESTORE DEFAULT
iPk
iPk
iPk
WEDGE
IBM AT or PS/2 PCs
i$1Bk
i$1Bk
i$1Bk
IBM XT
i$1Wk
i$1Wk
i$1Wk
PC Notebook
i$1ek
i$1ek
i$1ek
IBM SURE1
i$1k
i$1k
i$1k
IBM Terminal 3153
i$1^k
i$1^k
i$1^k
RS232 Fujitsu DEFAULT SETTINGS
9600 baud, no parity, 8 data bits, 1 stop bit, no handshaking,
delay disabled, rx timeout 2 sec., ack/nack disabled, FIFO
enabled, serial trigger lock disabled;
DATA FORMAT
: code identifier enabled, no field adjustment,
code length not transmitted, no header, terminator = CR,
character replacement disabled
RS232 ICL DEFAULT SETTINGS
9600 baud, parity even, 8 data bits, 1 stop bit, handshaking
RTS always on, delay disabled, rx timeout 9.9 sec., ack/nack
disabled, FIFO enabled, serial trigger lock disabled;
DATA FORMAT
: code identifier enabled, no field adjustment,
code length not transmitted, no header, terminator = CR,
character replacement disabled
WEDGE DEFAULT SETTINGS
USA keyboard, caps lock off, caps lock auto-recognition
enabled, num lock unchanged, inter-character and inter-
code delays disabled, control character emulation =
ctrl+shift+key;
DATA FORMAT
: code identifier disabled, no field adjustment,
code length not transmitted, no header, terminator =
ENTER, character replacement disabled
PEN EMULATION DEFAULT SETTINGS
interpret mode, conversion to code 39 disabled, output level
normal, idle level normal, minimum output pulse 600 µs,
overflow medium, inter-block delay disabled
POWER SAVE
scan rate max, standby disabled, sleep/USB suspended
disabled
READING PARAMETERS
hardware trigger, trigger active level, no trigger timeout,
Flash On = 1 sec, Flash Off = .6 sec, one read per cycle,
safety time .5 sec, beeper intensity high, tone 2, beeper
type monotone, beeper length short
DECODING PARAMETERS
ink spread enabled, overflow control enabled, interdigit
control enabled, Puzzle Solver™ disabled, decoding safety
= one read
