Chapter 4 – Menu System 47
DISPLAYED ITEM ITEM DESCRIPTION
ROW EMULATION Allows the row dots per inch to be adjusted (103 - 303), so that numbers smaller
than the printhead resolution enlarge the height of the printed output and numbers
larger reduce it, where:
XXX Dots
SOP EMULATION Allows label positioning commands to function with backward compatibility when
printing label formats designed for legacy models, where:
DISABLED Produces the natural start of print position. (Default Setting)
110 (PRODPLUS) Emulates the Prodigy Plus® start of print position.
220 (ALLEGRO) Emulates the Allegro® start of print position.
250 (PRODIGY) Emulates the Prodigy™ start of print position.
BACK AFTER PRINT Determines media movement when a cutter, present sensor, peel and present, or
GPIO is enabled, where:
MODE
Repositions media, where:
DISABLED Movement occurs only when the next label is ready to print, minimizing edge
curling. (Default Setting)
ENABLED
Movement occurs according to BACKUP DELAY timing after a cut, cleared sensor,
or SOP to allow fastest throughput.
BACKUP DELAY
(1/50s)
Instructs the printer to retract a presented label after a specified time elapses (0 –
255, in one-fiftieth of a second increments), where:
000 Retraction occurs when the next label is received and processed. (Default Setting)
FONT EMULATION Allows font substitution for all internal fonts, where:
STANDARD
FONTS
Prints using a standard (internal) font. (Default Setting)
CG TIMES Prints using the CG Times font.
USER ID S50 Prints using a downloaded font.
LABEL STORE Determines the command recall level used when retrieving stored label formats,
where:
STATE & FIELDS Recalls the printer state (i.e., heat, speed settings, etc.) and the label-formatting
commands for the stored label. (Default Setting)
FIELDS ONLY Recalls the label-formatting commands for the stored label.
MENU LANGUAGE Selects the menu and configuration label language. Only languages that are
resident will be displayed (see Appendix C), where:
ENGLISH Enables English (Default Setting)
DISPLAY SETTINGS
Determines the appearance of the items in the display, where:
GRAPHIC DISPLAY
MODE
Determines the magnification of the displayed items, where:
STANDARD
Is the normal setting.
ENHANCED Is the enlarged setting.
DISPLAY UNITS Determines the displayed type of distance information, where:
STANDARD Displays the information according to the UNITS OF MEASURE setting (see above).
IMPERIAL Displays the information in inches.
METRIC Displays the information in millimeters and centimeters.
DISPLAY
CONTRAST
Adjusts the displays contrast (0-100), where:
35 Is the default setting
To Next Page
