Datamax Mark II M-4206 User Manual

M-Class 131
5
Double-click ‘LPR
Port’.
6
In the top field enter the
IP address of your
printer. In the bottom
field enter PORT1.
When finished click
“OK’.
7
Click ‘Close’
8
Click ‘Next’.
9
Click on ‘Have Disk’.
10
Click ‘Browse’.

Datamax Mark II M-4206 Specifications

General

Print Resolution	203 dpi
Type	Label Printer
Print Method	Thermal Transfer
Max Print Speed	6 inches per second
Memory	16 MB SDRAM, 8 MB Flash
Interfaces	USB, Serial, Parallel
Media Width	4.5 inches
Media Length	0.25" to 99"
Max Print Width	4.25 inches (108 mm)
