22 M-Class
4.5.1 Printer Setup Menu List
The Printer Setup Menu List label, shown below, contains the printer’s current values for each menu item that can be
modified via the front panel (See Section 4.5.2 for a detailed item description.)
The Menu Item Numbers correspond to the item’s position in the Menu List for selection when pressing the
FEED
button during the Printer Setup Procedure (see Section 4.5). For example to “Direct Select” the BAUD RATE Menu Item
press and hold the
FEED
button for 7 flashes of the
ERROR
light and then release or for the TOF GAIN item hold
FEED
for 12 flashes, etc.
Menu
Items
Values
1) DIRECT = MEDIA TYPE
2) EDGE = SENSOR TYPE
3) NO = PRESENT SENSOR
4) NO = CUTTER EQUIPPED
5) 127 = SOP ADJUST, 0.005 in.
6) 127 = PRESENT ADJUST, 0.005 in.
7) 9600 = BAUD RATE, bps
8) 8 = DATA BITS
9) STD = CONTROL CODES
10) 100 = CONT FORM LENGTH, 0.01 in.
11) 3 = OOS MAXVOLT, 0.1 Volts
12) 12 = TOF GAIN
13) 10 = TOF DELTA, 0.1 Volts
14) 0 = TOF LOW, 0.1 Volts
15) 426 = LABEL WIDTH, 0.01 in.
16) 64 = SCALABLE FONT, 4KB
17) 128 = INTERNAL MODULE, 4KB
18) NO = LABEL ALIGNMENT
19) 100 = ALIGNMENT LENGTH, 0.01 in.
20) AUTO = OPTION CONTROL
21) DPL = INPUT MODE
22) STANDARD = DPL EMULATION
23) 10 = HEAT
24) NO = EXACT TIME
25) NO = GPIO
26) NO = NO REPRINT
Menu Item
Numbers
Note: When using narrow media, the ‘Menu Items’ column may be truncated.
