Datamax Mark II M-4206 User Manual

M-Class 61
5.1.8 MCL Options
MCL AT POWER-UP 
MCL (Macro Command Language) is tool suite designed for data collection
applications. The printer will accept input data from peripheral devices and the
application can request and send data to locally resident lookup files or remote
databases.
ENABLED
After power to the printer is turned ‘Off’ and ‘On,’ MCL will be started. The
printer is now ready to accept input data from peripheral devices such as barcode
scanners, weigh scales, and keyboards without the need of a host computer.
DISABLED
Normal printer functions.
START MCL 
MCL with be started after exiting from the menu.

Datamax Mark II M-4206 Specifications

General

Print Resolution	203 dpi
Type	Label Printer
Print Method	Thermal Transfer
Max Print Speed	6 inches per second
Memory	16 MB SDRAM, 8 MB Flash
Interfaces	USB, Serial, Parallel
Media Width	4.5 inches
Media Length	0.25" to 99"
Max Print Width	4.25 inches (108 mm)
