Category
Channel
Type
Signal\ Sensor Details
Default Channel
Options
Channel
Factor
Output
Units
More Information
Voltage
V
Voltage
input ranges are ±3V,
±300mV & ±30mV
(U)
Note 1
scaling
factor
mV
Voltage (P303)
HV
Higher Voltage
input ranges are ±50V (±30V
Series3 or older)
±3V & ±300mV
(A)
scaling
factor
V
Current
I
Current
(100,T)
Note 1, 2
current
shunt Ω
mA
Current(P306)
L
4-20mA current loop
(100)
Note 2
current
shunt Ω
%
Resistance
R
Resistance by 2, 3 or 4-wire
methods, 10KΩ, (1MΩ
Series4) maximum.
(I,3W)
offset adjust
Ω
Note 4
Ohm
Resistance (P308)
Bridge
BGI
4-wire bridge, 3-wire
simulated bridge
current excitation
(350,II,3W)
arm
resistance Ω
ppm
Bridges (P311)
BGV
4 & 6-wire bridges, voltage
excitation
(V,4W)
offset adjust
ppm
Note 4
ppm
Bridges (P311)
Frequency
F
Frequency measurement
(30,T)
Note 1
sample
period ms
Hz
Frequency (P323)
FW
Vibrating Wire Strain Gauge
frequency
DT80G/85G only
(200,MD350)
sample
period ms
Hz
Strain Gauges – Vibrating
Wire (P325)
Temperature
TB, TC, TD,
TE, TG, TJ
,
TK, TN, TR
,
TS, TT
Thermocouples Type B, C, D,
E, G, J, K, N, R, S and T
(T)
Note 1
scaling
factor
degC
Note 3
Temperature –
Thermocouples (P315)
PT385
PT392
Platinum RTDs
(α = 0.00385, 0.00392)
(100,3W,II)
0°C resist-
ance Ω
degC
Note 3
Temperature – RTDs
(P319)
NI
Nickel RTD
(α = 0.005001)
(1000,3W,I)
0°C resist-
ance Ω
degC
Note 3
CU
Copper RTD
(α = 0.0039)
(100,3W,II)
0°C resist-
ance Ω
degC
Note 3
YS01
YS02
YS03
YS04
YS05
YS06
YS07
YS16
YS17
Thermistors: Yellow Springs
400XX series
(3W,I)
parallel
resistor Ω
degC
Note 3
Temperature –
Thermistors (P317)
AD590
AD592
TMP17
Semiconductor current source
types (Analog Devices)
(100,V,U)
Note 2
current
shunt Ω
degC
Note 3
Temperature – AD590
Series IC Sensors (P319)
LM135
LM235
LM335
Semiconductor (zener diode)
voltage output types
(2,V)
voltage
divider
degC
Note 3
Temperature – LM135
Series IC Sensors (P322)
LM34
LM35
LM45
LM50
LM60
TMP35
TMP36
TMP37
Semiconductor voltage output
types
(V)
offset adjust
°C
Note 4
degC
Note 3
Temperature – LM35
Series IC Sensors (P321)
Time, Date
and System
Timers
T
writable
Time of day
Time (P37)
D
writable
Day or date
Date (P38)
