1: Introduction
1-2 PRC1077-MSOP
Technical Specifications
Note: Specifications are subject to change with notice or obligation.
Characteristic Specification
General
Frequency range 30 to 87.975 MHz
Available channels 2,320 channels with 25kHz frequency spacing
Preset channels 10 programmable memory channels
Channel programming Front panel
Modes FM; simplex, semi-duplex
Input power requirements 11 Vdc to 15 Vdc
Battery pack BB-LA6 sealed lead calcium; BA5598/U Lithium (case holds
spare battery)
Battery life 30 hours at 9:1 duty cycle (5W Tx) using BB-LA6 battery pack
Antennas 3 ft. tape and 10 ft. whip; 50 ohm antenna
Antenna port BNC for 50 ohm broadband antennas or for connection to
external amplifier; whip antenna port
Display Backlit, multi-function custom LED
Mechanical
Size 11.1 in. x 4.1 in. x 9.25 in. (28.2 cm x 10.5 cm x 23.5 cm);
W x H x D, including battery pack
Weight 9.7 lbs (4.4 kg), w/o battery pack; BB-LA6 pack is 2 lbs (0.9kg)
Package OD, sealed, including battery pack
Environmental
Temperature –40 to +60° C
Shock, vibration, humidity,
fungus, altitude
Per MIL-STD-810
Transmitter
RF power output 0.5W, 2W, or 5W (selectable)
Duty cycle Continuous service
Harmonics –50 dB
Receiver
Sensitivity 10 dB SINAD for 0.3 µV input
Squelch 150 Hz tone, carrier; selectable
Audio 500 mW into 16 ohms; 50 mW at 150 ohms; 0 dBm into
600 ohms
