PRC1099A-MSOP
PRC1099A
Radio Set
Operator Manual
Datron W
orld Communications Inc.
Manual Part No. PRC1099A-MSOP
Release Date: May 2007
Re
vision: C
3030 Enterprise Court
V
ista, CA 92081, U.S.A.
Phone: (760) 597-150
0 Fax
: (760) 597-1510
E-Mail: sales@dtwc.com
www
.dtwc.com
2
Table of Contents
Default Chapter
7
Table of Contents
7
Chapter 1: Introduction
9
The PRC1099A
9
Technical Specifications
10
Single Sideband and HF Communications
11
Chapter 2: Installation
15
Unpacking
15
Location Considerations
15
Manpack Installation
16
Figure 2-2. Manpack Harness Installation
18
Mobile Installations
20
Figure 2-4. Mobile 100W System
21
Figure 2-5. Mobile 400W System
22
Base Installations
23
Connecting Audio Accessories
24
Battery Charger Installation
24
Figure 2-6. Charging a Battery Using PRC-PS and PRC1099A
25
Figure 2-7. Charging a Battery Using PRC-PS
26
Figure 2-8. Charging Multiple Batteries Using PRC-BC4
27
Figure 2-9. Charging a Battery Using the PRC-HC-30 and PRC1099A
28
Figure 2-11. Charging a Battery Using PRC-SPU-10 and PRC1099A
29
Internal Battery Charger Option
30
Chapter 3: Operation
31
Quick Start
31
Using Knobs, Connectors and Indicators
32
Tuning the Antenna
35
Jamming
35
CW Operation
36
Chapter 4 : Radio Programming
37
Display Area
37
Radio Programming
37
Menu Navigation
37
Setting Channels and Frequencies
39
Standard Option Menu
40
The Menu
40
Standard Data Menu
42
Standard Scan Menu
44
Optional ALE Menu
46
Optional Message Menu
56
Optional Call Menu
58
Optional Transadapt/Transcall Menu
61
Chapter 5 : Maintenance
65
Preventive Maintenance
65
Table 5-2. Weekly Preventive Maintenance
66
BITE System
69
Chapter 6 : Antenna Systems
71
Short Whip Antenna
71
Internal Antenna Tuner
71
Ground Systems
72
End-Fed Antennas
72
Figure 6-1. Whip Antenna Configuration
73
Figure 6-3. Resonant Dipole Antenna Configuration
74
Figure 6-5. Mobile Configuration with Remote Antenna Tuner
75
Optional Accessories
77
Chapter 7 : Optional Accessories
77
Rechargeable Batteries
77
Non-Rechargeable Batteries
77
Power Cables
78
Carrying Cases
78
Audio Equipment
78
Manpack and Long Range Antennas
79
Amplifiers and Power Supplies
80
Antenna Tuners
81
Shock Mounts
81
Vehicle Mounts
81
