4: Radio Programming
PRC1099A-MSOP 4-7
Menu
Selections
The following table describes each of the selections within the DATA menu.
Selection Description
SRC SEL Source Select. For selecting the source from which the
data to the accessory connector is originating. Sources are
either the keyfill device (KEY) or some remote (RMT)
peripheral.
BAUD RAT Baud Rate. For selecting the baud rate of the data to and
from the radio accessory connector (75 to 9600 baud).
DATA BIT Data Bit. For selecting the number of data bits (7 or 8)
used to communicate through the accessory connector.
STOP BIT Stop Bit. For selecting the number of stop bits (1 or 2)
required to communicate through the accessory
connector.
PARITY Parity. For selecting the parity of the data: E (even), O
(odd), or N (none).
FLOW CTL Flow control. Not enabled. Controls the character flow-
control protocol of the input and output data. Flow control
refers to XON and XOFF characters inserted into the
stream of data as flow control markers indicating the
beginning and end of data streams.
RAD ADDR Radio Address. For selecting the address number of this
radio when more than one radio is connected on the same
data bus (00 through 99).
To Next Page
