6: Antenna Systems
PRC1099A-MSOP 6-5
Figure 6-5. Mobile Configuration with Remote Antenna Tuner
4.2M Whip
Ground tuner to
body #4 AWG
(As short as possible)
Feed-through
insulator
Antenna RF lead
(as short as
possible
)
PRC1099A in
MT-1099A vehicle mount
with RA100 amplifier
Figure 6-6. Remote Tuned Antenna Configuration
Longwire antenna
RAT7000B Tuner
Grounded to metal
building structure
PRC1099A
(MT-1099A
re
q
uired with it
)
