4: Radio Programming
PRC1099A-MSOP 4-5
Menu
Selections
The following table describes each of the selections within the OPT menu.
Selection Description
T/A SEL TransAdapt Select. Enables the TransAdapt option if
installed. If not installed, this menu is not displayed. If both
TransAdapt and ALE options are installed, activating one
option automatically deactivates the other.
ALE SEL ALE Select. Enables the ALE option, if installed. If not
installed, this menu is not displayed. If both the TransAdapt
and ALE options are installed, activating one option
automatically deactivates the other.
BITE TST Built-in-Test Equipment Test. Enables the BITE system.
Once enabled, the BITE function takes control of the radio
and performs all necessary checks before returning control
to the operator. After BITE is completed, the result is
displayed on the front panel.
FQLOKSEL Frequency Lock Select. Prevents the radio channel
frequencies from being changed accidentally. Once
activated, the channel frequencies cannot be changed, until
deactivated.
BAT TEST Battery Test. Checks the battery voltage. The battery is
checked in increments of 0.25 Vdc. BATT BAD indicates
the battery is either below 10.5 or above 15 Vdc.
TUNER Tuner. For selecting the Datron tuner to use with the
PRC1099A.
PASSWORD Password. For entering a password to allow access to all
menus. If the correct password (five letter maximum) is
entered, the LOCK SEL and NEW PWRD selections are
accessible. If an incorrect password is entered,
NONE is
displayed and LOCK SEL and NEW PWRD selections are
not accessible.
LOCK SEL Lock select. Locks out access to DATA and ALE menus.
This prevents unauthorized alterations of settings in those
two menus.
NEW PWRD New Password. For entering a new password or to change
an existing password. If no password exists, selecting
LOCK SEL displays NONE. LOCK SEL is allowed access
only when the same password is entered. To remove a
password, enter a blank password, scroll to and press
WHIP TUNE.
