4: Maintenance
PRC1077-MSOP 4-3
11. The PRC1077 is designed with four internal test bands selected
automatically by the microprocessor. Perform steps 8 and 9 in each of the
four frequency band ranges listed below:
• 30 MHz to 39 MHz
• 40 MHz to 51.975 MHz
• 52 MHz to 67.975 MHz
• 68 MHz to 87.975 MHz
Figure 4-1. PRC1077 Replacement Parts
B
attery
Box
Transceiver
Case
Protective
Power
Cap
Protective
BNC Cap
Protective
Antenna
Cap
Power
Knob
Channel
Knob
Tuning
Knob
(kHz)
Tuning
Knob
(kHz)
Function
Knob
(kHz)
Volume
Knob
Hinge
Captive
Screw
Protective
Dual Audio
Cap
Tuning
Knob
(MHz)
