6: Power Amplifier Board
PRC1099A-MS 6-9
Table 6-3 Power Amplifier Board Parts List (009-00403 Rev. F)
Designator Part Number Description
C10 021104011 “CAP, 0.1UF, X7R, 100V, 10%, 1206”
C11 021226002 “CAP, 22UF X5R 6.3V 20% 1206”
C12 021102001 “CAP, 1000PF 50V X7R 10% 0603”
C13 021102001 “CAP, 1000PF 50V X7R 10% 0603”
C14 021104011 “CAP, 0.1UF, X7R, 100V, 10%, 1206”
C15 022226003 “CAP,22UF TA L-ESR 35V 10% 7343”
C16 022107004 “CAP,100UF,TA,20V,20%,7343-43”
C16A 022107004 “CAP,100UF,TA,20V,20%,7343-43”
C17 021104006 “CAP,0.1UF,X7R,25V,10%,0603”
C17A 021104006 “CAP,0.1UF,X7R,25V,10%,0603”
C18 021102007 “CAP, 1000PF NP0 200V 5% 1206”
C19 021102007 “CAP, 1000PF NP0 200V 5% 1206”
C2 021104006 “CAP,0.1UF,X7R,25V,10%,0603”
C20 021104011 “CAP, 0.1UF, X7R, 100V, 10%, 1206”
C21 021102007 “CAP, 1000PF NP0 200V 5% 1206”
C22 021102007 “CAP, 1000PF NP0 200V 5% 1206”
C23 021104011 “CAP, 0.1UF, X7R, 100V, 10%, 1206”
C25 021104000 “CAP, 0.1UF X7R 25V 5% 0805”
C26 022226003 “CAP,22UF TA L-ESR 35V 10% 7343”
C27 021104011 “CAP, 0.1UF, X7R, 100V, 10%, 1206”
C28 021104011 “CAP, 0.1UF, X7R, 100V, 10%, 1206”
C29 022107002 “CAP,100UF TA LESR 16V 10% 7343”
C30 021102000 “CAP, 1000PF NP0 100V 5% 0805”
C31 021104006 “CAP,0.1UF,X7R,25V,10%,0603”
C32 021104006 “CAP,0.1UF,X7R,25V,10%,0603”
C33 021104006 “CAP,0.1UF,X7R,25V,10%,0603”
C34 021104006 “CAP,0.1UF,X7R,25V,10%,0603”
C35 021104006 “CAP,0.1UF,X7R,25V,10%,0603”
C36 021104006 “CAP,0.1UF,X7R,25V,10%,0603”
C37 021105010 “CAP, 1UF X7R 16V 10% 0603”
C38 021105010 “CAP, 1UF X7R 16V 10% 0603”
