13: Internal Options
13-14 PRC1099A-MS
13.2 Internet Protocol Interface (PRC1099A-IP)
When the PRC1099A is installed in the MT-1099A vehicle mount, the
PRC1099A-IP option provides an Ethernet interface allowing the operation of
remote control and data application software over a 10Base-T Ethernet
TCP/IP network.
For more information about the PRC1099A-IP, refer to the Internet Protocol
Interface Operator manual (IPI-MSOP).
U15 033049 “IC,SMT 32 X 8 SRAM, SOJ-28-5”
U16 033057 “IC, 74HC00 QUAD 2-I NAND SOIC14”
U17 033304057 “IC, LMC6492A, DUAL OP-AMP, SOIC-8”
U2 065116000 “OSC, 11.0592MHZ 5V 7X5MM”
U20 010-00101 PROGRAMMED GAL
U21 033058 “IC,74HC573A OCTAL LATCH SOW-20”
U22 033059 “IC,74ACT14M DIGITAL, SO-14”
U23 033303152 “IC, 7SZ74 SINGLE D-FF US-8”
U3 033051 “IC, UCNTLR 80C31 PLCC-44”
U30 033303146 “IC, LV QUAD BUFFER TSSOP14”
U31 033303049 IC SM DIG 74HCT125 SOIC
U32 034400011 “IC, LT1761, LDO VREG, 0.1A, ADJ, SOT23-5”
U5 033300001 “IC, 32KX8 SRAM 70NS SOIC-28”
U6 033050 “IC, 28C64 8KX8 EEPROM PLCC32”
U7 033050 “IC, 28C64 8KX8 EEPROM PLCC32”
U9 033300031 “IC, SRAM, 1KX8 DUAL PORT, PLCC-52”
XU80 089032000 “SOCKET, PLCC32 SMT”
XU94 089032000 “SOCKET, PLCC32 SMT”
XU98 089032000 “SOCKET, PLCC32 SMT”
Table 13-2 ALE Board Parts List (010-00200 Rev. V)
Designator Part Number Description
